Toro Dingo Hydraulic Oil Chart

Toro Dingo Hydraulic Oil for TX220, TX320, TX323, TX427, TX525 and TX-1000 models.

Model
Serial
Oil
22300
All
Mobil 424 46/64 ISO Toro #95-2836
22302
All
Mobil 424 46/64 ISO Toro #95-2836
22303
1999 thru 2001
Mobil 424 46/64 ISO Toro #95-2836

2002 and Newer
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent
22304
All
Mobil 424 46/64 ISO Toro #95-2836
22305
1999 thru 2001
Mobil 424 46/64 ISO Toro #95-2836

2002 and Newer
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent
22311
All
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent
22312
All
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent
22317
All
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent
22318
All
CH-4 or Higher, Diesel Engine Motor oil 10W-30 or 15W-40 Detergent



Note: Toro’s hydraulic oil recommendation for your Sitework Systems product. This is necessary due to a change in the formulation for the latest diesel motor oil API specification, CJ-4. It has a reduced amount of ZDDP anti-wear additive and no longer meets the hydraulic system requirements for Sitework Systems products.

Approved Hydraulic Fluids:

  • Premium All-Season Hydraulic Fluid (Mobil DTE-15M Special), which is blended for and available from Toro. This fluid is hydraulic oil and contains a red dye to help in locating oil leaks that may occur. Part # 108-1178
  • Premium Transmission / Hydraulic Tractor Fluid (Mobil 424 Tractor Fluid), also available from Toro. Part # 108-1184



These fluids are compatible and can be mixed together. In the event that none of these fluids is readily available please contact ProParts Direct for possible alternative “industry equivalent” fluid.

Dingo Hydraulic Pressure and Flow Chart

Model
Wheel/Loader Pressure
Auxillary Pressure
Pump Flow
22306
3250 psi @ Drive Circuit Test Port
1950 psi @ loader circuit test port
3000 psi @ couplers
9 gal & 4 gal
22306
2450 psi @ 2 Spool Valve
3000 psi @ Couplers
11 gal & 5.5 gal
22307
2450 psi @ 2 Spool Valve
3000 psi @ Couplers
11 gal & 5.5 gal
22308
2650 psi @ 2 Spool Valve
2650 psi @ Couplers
6.9 Gal
22317
3000 psi @ Drive Circuit Test Port
1950 psi @ loader circuit test port
3000 psi @ Couplers
10.8 gal & 4 gal
22318
3000 psi @ Drive Circuit Test Port
1950 psi @ loader circuit test port
3000 psi @ Couplers
10.8 gal & 4 gal
