Repalces Kohler parts numbers 25 083 01 and 24 083 04-S.
Fits models CV-16 to CV-26, CH730-CH750, CV740, CV745, CH18-CH26, LH640, LH685 and LH690.
|
OD 4-3/8"
ID 3"
Height: 1-1/2"
| Replaces:
Kohler Part 230840S
Used on:
4 6-1/4 and 7hp Engines. K90, K91. K141, and K161 series
|
|
|
|
OD: 7"
ID: 5-1/2"
Height: 2-1/2"
| Replaces:
Kohler Part
Used on:
10 12& 14hp Engines K241, K30, 1K321 series
|
|
OD: 6"
ID: 4-5/8
Height: 3"
| Replaces:
Kohler Part 45-083-02-S
Used on:
16hp Engines K341 series MV16 thru 20, M10 thru M16
|
|
OD: 6"
ID: 4-5/8"
Height: 4"
| Replaces:
Kohler Part 277138
Used on:
18,20 & 23hp engines. K482, K532 & K582
|
|
